With standard drive on flipper guides for easy loading and a tough aluminium frame this trailer is ready to hit the boat ramp and you can even option up with a walkway and spare wheel.
Specifications
|
Aggregate Trailer Mass 1298 Kg |
|
Brakes Yes |
|
Gross Trailer Mass 280 Kg |
|
Length Overall 6.07 M |
|
Springs 6.00 |
|
Tare Weight 1,180.00 Kg |
|
Tyre 165 |
|
Wheel 13 " |
|
Width Between Guards 1.80 M |
|
Width Overall 2.25 M |
Features
|
Aluminium Cross Members (4) |
|
Axle Galvanised 45mm Square Braked |
|
Brakes - Override Mechanical |
|
Drawbar 75mm Hot Dipped Galvanised |
|
Easy Loader Drive On Cradle |
|
Galvanised 6 Leaf Suspension Springs |
|
Jockey Wheel - Swing Up |
|
Lights: Submersible LED Forward Facing Lights (2) |
|
Lights: Submersible LED Tail Lights |
|
Lights: Submersible LED Wide Clearance Lights (2) |
|
Rolled Aluminium Trailer Frame |
|
Supports: Galvanised Adjustable Dual Keel Rollers (2) |
|
Supports: Galvanised Adjustable Keel Rollers (2) |
|
Supports: Galvanised Adjustable Long Teflon Skids (2) |
|
Tie Down Points Front & Rear |
|
Wheels: 13" Alloy Sports |
|
Winch: 5:1 Ratio 500kg & Webbing Strap |
Options
|
7 Pin Flat Plug |
|
7 Pin Plug Round LARGE |
|
7 Pin Round SMALL |
|
Motor Support Bracket |
|
Spare Wheel & Carrier 13" Black Alloy |
|
Swing-away Drawbar |
|
Trailer Walkway |
